Texas Instruments ULN2003ADR

Part No.:
ULN2003ADR
Manufacturer:
Texas Instruments
Category:
Power Distribution Switches, Load Drivers
Package:
16-SOIC (0.154", 3.90mm Width)
Datasheet:
Chuangxin CloudULN2003ADR.pdf
Description:
IC PWR RELAY 7NPN 1:1 16SOIC
Quantity:

Unit Price:$0

Ext Price:$0

Payment:
Payment
Shipping:
Shipping

Product details

  • Specifications
  • FAQ
  • Comparison
  • Tags
Product attributes
Attribute value
Manufacturer:
Texas Instruments
Package/Case:
16-SOIC (0.154", 3.90mm Width)
Series:
ULx200xA
Packaging:
Tape & Reel (TR)
Product Status:
Active
Switch Type:
Relay, Solenoid Driver
Number of Outputs:
7
Ratio - Input:Output:
1:1
Output Configuration:
Low Side
Output Type:
Darlington
Interface:
Parallel
Voltage - Load:
50V (Max)
Voltage - Supply (Vcc/Vdd):
Not Required
Current - Output (Max):
500mA
Rds On (Typ):
-
Input Type:
Inverting
Features:
-
Fault Protection:
-
Operating Temperature:
-40°C ~ 70°C (TA)
Grade:
-
Qualification:
-
Mounting Type:
Surface Mount
Supplier Device Package:
16-SOIC
Datasheet:
Chuangxin CloudULN2003ADR.pdf
