Texas Instruments UCC3895DW

Part No.:
UCC3895DW
Manufacturer:
Texas Instruments
Category:
DC DC Switching Controllers
Package:
20-SOIC (0.295", 7.50mm Width)
Datasheet:
Chuangxin CloudUCC3895DW.pdf
Description:
IC OFFLINE SW FULL-BRDG 20SOIC
Quantity:

Unit Price:$0

Ext Price:$0

Payment:
Payment
Shipping:
Shipping

Product details

  • Specifications
  • FAQ
  • Comparison
  • Tags
Product attributes
Attribute value
Manufacturer:
Texas Instruments
Series:
-
Package/Case:
20-SOIC (0.295", 7.50mm Width)
Packaging:
Tube
Product Status:
Active
Output Type:
PWM
Function:
-
Output Configuration:
Positive
Topology:
Phase-Shifted Full-Bridge
Number of Outputs:
1
Output Phases:
1
Voltage - Supply (Vcc/Vdd):
10V ~ 16.5V
Frequency - Switching:
1MHz
Duty Cycle (Max):
100%
Synchronous Rectifier:
-
Clock Sync:
Yes
Serial Interfaces:
-
Control Features:
Frequency Control, Soft Start, Sync
Operating Temperature:
0°C ~ 70°C (TA)
Grade:
-
Qualification:
-
Mounting Type:
Surface Mount
Supplier Device Package:
20-SOIC
Datasheet:
Chuangxin CloudUCC3895DW.pdf
