STMicroelectronics TN3015H-6G

Part No.:
TN3015H-6G
Manufacturer:
STMicroelectronics
Category:
SCRs
Package:
TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
Datasheet:
Chuangxin CloudTN3015H-6G.pdf
Description:
SCR 600MV 30A D2PAK
Quantity:

Unit Price:$0

Ext Price:$0

Payment:
Payment
Shipping:
Shipping

Product details

  • Specifications
  • FAQ
  • Comparison
  • Tags
Product attributes
Attribute value
Manufacturer:
STMicroelectronics
Series:
ECOPACK®2
Package/Case:
TO-263-3, D2PAK (2 Leads + Tab), TO-263AB
Packaging:
Tube
Product Status:
Active
Voltage - Off State:
600 V
Voltage - Gate Trigger (Vgt) (Max):
1.3 V
Current - Gate Trigger (Igt) (Max):
15 mA
Voltage - On State (Vtm) (Max):
1.6 V
Current - On State (It (AV)) (Max):
19 A
Current - On State (It (RMS)) (Max):
30 A
Current - Hold (Ih) (Max):
60 mA
Current - Off State (Max):
10 µA
Current - Non Rep. Surge 50, 60Hz (Itsm):
270A, 295A
SCR Type:
Standard Recovery
Operating Temperature:
-40°C ~ 150°C (TJ)
Grade:
-
Qualification:
-
Mounting Type:
Surface Mount
Supplier Device Package:
D2PAK
Datasheet:
Chuangxin CloudTN3015H-6G.pdf
