TE Connectivity Aerospace, Defense and Marine JMACD-26XM

Part No.:
JMACD-26XM
Manufacturer:
TE Connectivity Aerospace, Defense and Marine
Category:
Signal Relays, Up to 2 Amps
Package:
Datasheet:
Chuangxin CloudJMACD-26XM.pdf
Description:
RELAY GEN PURPOSE DPDT 1A 26.5V
Quantity:

Unit Price:$0

Ext Price:$0

Payment:
Payment
Shipping:
Shipping

Product details

  • Specifications
  • FAQ
  • Comparison
  • Tags
Product attributes
Attribute value
Manufacturer:
TE Connectivity Aerospace, Defense and Marine
Series:
MAD, CII
Packaging:
Bulk
Product Status:
Active
Mounting Type:
Through Hole
Coil Voltage:
26.5VDC
Contact Form:
DPDT (2 Form C)
Contact Rating (Current):
1 A
Switching Voltage:
115VAC, 28VDC - Max
Load - Max Switching:
115VA, 28W
Coil Current:
17 mA
Coil Type:
Non Latching
Features:
Diode
Termination Style:
PC Pin
Seal Rating:
Sealed - Hermetically
Coil Insulation:
-
Must Operate Voltage:
14.2 VDC
Must Release Voltage:
1.37 VDC
Operate Time:
2 ms
Release Time:
4 ms
Operating Temperature:
-65°C ~ 125°C
Contact Material:
Silver Palladium (AgPd), Gold (Au)
Relay Type:
General Purpose
Grade:
Military
Qualification:
MIL-R-39016/15
Datasheet:
Chuangxin CloudJMACD-26XM.pdf
