National Semiconductor DS2004CM

Part No.:
DS2004CM
Manufacturer:
National Semiconductor
Category:
Bipolar Transistor Arrays
Package:
16-SOIC (0.154", 3.90mm Width)
Datasheet:
Chuangxin CloudDS2004CM.pdf
Description:
TRANS 7NPN DARL 55V 500MA 16SOIC
Quantity:

Unit Price:$0

Ext Price:$0

Payment:
Payment
Shipping:
Shipping

Product details

  • Specifications
  • FAQ
  • Comparison
  • Tags
Product attributes
Attribute value
Manufacturer:
National Semiconductor
Series:
-
Package/Case:
16-SOIC (0.154", 3.90mm Width)
Packaging:
Bulk
Product Status:
Active
Transistor Type:
7 NPN Darlington
Current - Collector (Ic) (Max):
500mA
Voltage - Collector Emitter Breakdown (Max):
55V
Vce Saturation (Max) @ Ib, Ic:
1.6V @ 500µA, 350mA
Current - Collector Cutoff (Max):
500µA
DC Current Gain (hFE) (Min) @ Ic, Vce:
-
Power - Max:
926mW
Frequency - Transition:
-
Operating Temperature:
0°C ~ 85°C
Grade:
-
Qualification:
-
Mounting Type:
Surface Mount
Supplier Device Package:
16-SOIC
Datasheet:
Chuangxin CloudDS2004CM.pdf
