Eaton - Electronics Division LDS0705-8R2M-R

Part No.:
LDS0705-8R2M-R
Manufacturer:
Eaton - Electronics Division
Category:
Fixed Inductors
Package:
Nonstandard
Datasheet:
Chuangxin CloudLDS0705-8R2M-R.pdf
Description:
FIXED IND 8.2UH 2.67A 33MOHM SMD
Quantity:

Unit Price:$0

Ext Price:$0

Payment:
Payment
Shipping:
Shipping

Product details

  • Specifications
  • FAQ
  • Comparison
  • Tags
Product attributes
Attribute value
Manufacturer:
Eaton - Electronics Division
Series:
LDS0705
Package/Case:
Nonstandard
Packaging:
Tape & Reel (TR)
Product Status:
Obsolete
Type:
Drum Core, Wirewound
Material - Core:
Ferrite
Inductance:
8.2 µH
Tolerance:
±20%
Current Rating (Amps):
2.67 A
Current - Saturation (Isat):
2.86A
Shielding:
Shielded
DC Resistance (DCR):
33mOhm
Q @ Freq:
-
Frequency - Self Resonant:
-
Ratings:
-
Operating Temperature:
-40°C ~ 125°C
Inductance Frequency - Test:
100 kHz
Features:
-
Mounting Type:
Surface Mount
Supplier Device Package:
-
Size / Dimension:
0.307" L x 0.276" W (7.80mm x 7.00mm)
Height - Seated (Max):
0.197" (5.00mm)
