Diotec Semiconductor LL103B

Part No.:
LL103B
Manufacturer:
Diotec Semiconductor
Category:
Single Diodes
Package:
DO-213AC, MINI-MELF, SOD-80
Datasheet:
Chuangxin CloudLL103B.pdf
Description:
DIODE SCHOTTKY 30V 0.35A SOD80C
Quantity:

Unit Price:$0

Ext Price:$0

Payment:
Payment
Shipping:
Shipping

Product details

  • Specifications
  • FAQ
  • Comparison
  • Tags
Product attributes
Attribute value
Manufacturer:
Diotec Semiconductor
Series:
-
Package/Case:
DO-213AC, MINI-MELF, SOD-80
Packaging:
Tape & Reel (TR)
Product Status:
Active
Technology:
Schottky
Voltage - DC Reverse (Vr) (Max):
30 V
Current - Average Rectified (Io):
350mA
Voltage - Forward (Vf) (Max) @ If:
600 mV @ 200 mA
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr):
10 ns
Current - Reverse Leakage @ Vr:
5 µA @ 20 V
Capacitance @ Vr, F:
50pF @ 0V, 1MHz
Grade:
-
Qualification:
-
Mounting Type:
Surface Mount
Supplier Device Package:
SOD-80C
Operating Temperature - Junction:
-55°C ~ 125°C
Datasheet:
Chuangxin CloudLL103B.pdf
