Home > Products > Connectors, Interconnects > Terminals > Turret Connectors

Turret Connectors

制造商	Series	Packaging	Product Status	Terminal Type	Number of Turrets	Length - Above Board	Length - Below Flange	Length - Overall	Mounting Type	Termination	Flange Diameter	Diameter - Turret Head	Staking Side OD	Staking Side ID	Mounting Hole Diameter	Board Thickness	Contact Material	Contact Finish	Contact Finish Thickness	Insulation
ASSMANN WSW Components Harwin Inc. Keystone Electronics Mill-Max Manufacturing Corp. Pomona Electronics	- 0700 0730 1064 1068 1070 1071 1072 1092 1093 1095 1096 1106 1122 2101 2102 2106 2108 2109 2110 2111 2113 2301 2304 2305 2306 2307 2308 2309 2310 2311 2312 2313 2316 2317 2318 2321 2324 2325 2329 2333 2348 2352 2355 2365 2501 2503 2505 2506 2508 2510 2512 2513 2524 2533 2551 2561 2702 2703 2704 2705 2706 2707 2708 2709 2710 2713 2717 2801 2802 2803 2804 2805 2806 2810 2811 2812 2815 2816 2817 2821 3156 3408 ECS-2333	Bag Bulk	Active Obsolete	- Double End Double End, Fork Double End, Pin PC Pin Single End Single End, Fork Single End, Fork, Hollow Single End, Hollow Single End, Tapered	- Double Single Single, Double Triple	- 0.070" (1.78mm) 0.076" (1.93mm) 0.078" (1.98mm) 0.093" (2.36mm) 0.094" (2.39mm) 0.104" (2.64mm) 0.109" (2.77mm) 0.118" (3.00mm) 0.120" (3.05mm) 0.125" (3.18mm) 0.126" (3.20mm) 0.131" (3.33mm) 0.135" (3.43mm) 0.136" (3.45mm) 0.138" (3.50mm) 0.140" (3.56mm) 0.142" (3.61mm) 0.150" (3.81mm) 0.151" (3.84mm) 0.156" (3.96mm) 0.157" (4.00mm) 0.158" (4.01mm) 0.159" (4.04mm) 0.172" (4.37mm) 0.173" (4.39mm) 0.176" (4.47mm) 0.177" (4.50mm) 0.181" (4.60mm) 0.183" (4.65mm) 0.186" (4.72mm) 0.187" (4.75mm) 0.188" (4.78mm) 0.190" (4.83mm) 0.191" (4.85mm) 0.192" (4.88mm) 0.194" (4.93mm) 0.195" (4.95mm) 0.196" (4.98mm) 0.203" (5.15mm) 0.207" (5.26mm) 0.210" (5.33mm) 0.213" (5.41mm) 0.217" (5.50mm) 0.219" (5.56mm) 0.221" (5.61mm) 0.230" (5.84mm) 0.234" (5.94mm) 0.236" (6.00mm) 0.237" (6.02mm) 0.238" (6.05mm) 0.241" ~ 0.261" (6.12mm ~ 6.62mm) 0.243" (6.17mm) 0.246" ~ 0.261" (6.25mm ~ 6.63mm) 0.247" ~ 0.260" (6.27mm ~ 6.60mm) 0.250" (6.35mm) 0.256" (6.50mm) 0.257" (6.52mm) 0.266" (6.76mm) 0.270" (6.86mm) 0.281" (7.14mm) 0.283" (7.20mm) 0.287" (7.29mm) 0.290" (7.37mm) 0.301" (7.65mm) 0.303" (7.70mm) 0.307" (7.80mm) 0.310" (7.87mm) 0.312" (7.92mm) 0.318" ~ 0.338" (8.08mm ~ 8.58mm) 0.323" (8.20mm) 0.328" (8.33mm) 0.340" (8.64mm) 0.343" (8.70mm) 0.344" (8.74mm) 0.344" ~ 0.363" (8.74mm ~ 9.23mm) 0.350" (8.89mm) 0.354" ~ 0.362" (9.00mm ~ 9.20mm) 0.359" (9.12mm) 0.360" (9.14mm) 0.368" (9.35mm) 0.370" (9.40mm) 0.375" (9.53mm) 0.390" (9.91mm) 0.391" (9.93mm) 0.405" (10.29mm) 0.422" (10.72mm) 0.425" (10.80mm) 0.433" ~ 0.441" (11.00mm ~ 11.20mm) 0.437" (11.10mm) 0.453" (11.51mm) 0.454" (11.53mm) 0.460" (11.68mm) 0.469" (11.91mm) 0.484" (12.29mm) 0.500" (12.70mm) 0.510" (12.95mm) 0.547" (13.89mm) 0.587" ~ 0.606" (14.90mm ~ 15.40mm) 0.594" (15.09mm) 0.744" ~ 0.764" (18.90mm ~ 19.40mm) 0.938" (23.83mm)	- 0.035" (0.89mm) 0.045" (1.14mm) 0.049" (1.24mm) 0.051" (1.30mm) 0.052" (1.32mm) 0.053" (1.35mm) 0.054" (1.37mm) 0.058" (1.47mm) 0.062" (1.57mm) 0.063" (1.60mm) 0.072" (1.83mm) 0.074" (1.88mm) 0.075" (1.91mm) 0.077" (1.96mm) 0.078" (1.98mm) 0.080" (2.03mm) 0.082" (2.08mm) 0.082" ~ 0.084" (2.08mm ~ 2.13mm) 0.084" (2.13mm) 0.085" (2.16mm) 0.087" (2.21mm) 0.089" (2.26mm) 0.089" ~ 0.094" (2.26mm ~ 2.39mm) 0.092" ~ 0.097" (2.34mm ~ 2.46mm) 0.093" (2.36mm) 0.094" (2.39mm) 0.094" ~ 0.099" (2.39mm ~ 2.51mm) 0.098" (2.50mm) 0.100" (2.54mm) 0.100" ~ 0.110" (2.54mm ~ 2.79mm) 0.102" (2.60mm) 0.103" (2.62mm) 0.105" (2.67mm) 0.107" (2.72mm) 0.109" (2.77mm) 0.110" (2.79mm) 0.111" (2.82mm) 0.113" (2.87mm) 0.115" (2.92mm) 0.118" (3.00mm) 0.120" (3.05mm) 0.124" (3.15mm) 0.125" (3.18mm) 0.125" ~ 0.130" (3.18mm ~ 3.30mm) 0.126" (3.20mm) 0.130" (3.30mm) 0.133" (3.38mm) 0.135" (3.43mm) 0.137" (3.48mm) 0.140" (3.56mm) 0.141" (3.58mm) 0.143" (3.63mm) 0.145" (3.68mm) 0.147" (3.73mm) 0.150" (3.81mm) 0.156" (3.96mm) 0.156" ~ 0.161" (3.96mm ~ 4.09mm) 0.164" (4.17mm) 0.165" (4.19mm) 0.167" (4.24mm) 0.171" (4.34mm) 0.172" (4.37mm) 0.174" (4.42mm) 0.176" (4.47mm) 0.181" (4.60mm) 0.186" (4.72mm) 0.187" (4.75mm) 0.188" (4.78mm) 0.194" (4.93mm) 0.195" (4.95mm) 0.197" (5.00mm) 0.205" (5.20mm) 0.207" (5.26mm) 0.209" (5.31mm) 0.212" (5.39mm) 0.215" (5.46mm) 0.217" (5.51mm) 0.218" (5.54mm) 0.219" (5.56mm) 0.224" (5.69mm) 0.226" (5.74mm) 0.227" (5.77mm) 0.230" (5.84mm) 0.234" (5.94mm) 0.236" (6.00mm) 0.238" (6.05mm) 0.239" (6.07mm) 0.244" ~ 0.252" (6.20mm ~ 6.40mm) 0.246" (6.25mm) 0.249" (6.32mm) 0.250" (6.35mm) 0.255" (6.48mm) 0.258" (6.55mm) 0.259" (6.58mm) 0.260" (6.60mm) 0.270" (6.86mm) 0.277" (7.04mm) 0.281" (7.14mm) 0.282" (7.16mm) 0.287" (7.29mm) 0.289" (7.34mm) 0.301" (7.65mm) 0.303" (7.70mm) 0.305" (7.75mm) 0.309" (7.85mm) 0.312" (7.92mm) 0.313" (7.95mm) 0.320" (8.13mm) 0.334" (8.48mm) 0.344" (8.74mm) 0.363" (9.22mm) 0.370" (9.40mm) 0.375" (9.53mm) 0.395" (10.03mm) 0.403" (10.24mm) 0.417" (10.59mm) 0.425" (10.80mm) 0.447" (11.35mm) 0.477" (12.12mm) 0.510" (12.95mm) 0.516" (13.11mm) 0.532" (13.51mm) 0.535" (13.59mm) 0.542" (13.77mm) 0.550" (13.97mm) 0.561" (14.25mm) 0.565" (14.35mm) 0.600" (15.24mm) 0.650" (16.51mm) 0.662" (16.81mm) 0.672" (17.07mm) 0.675" (17.15mm) 0.680" (17.27mm) 0.949" (24.10mm)	- 0.123" (3.12mm) 0.129" (3.28mm) 0.146" (3.71mm) 0.147" (3.73mm) 0.148" (3.76mm) 0.154" (3.91mm) 0.155" (3.94mm) 0.160" (4.06mm) 0.176" (4.47mm) 0.177" (4.50mm) 0.178" (4.52mm) 0.185" (4.70mm) 0.186" (4.72mm) 0.188" (4.78mm) 0.193" (4.90mm) 0.197" (5.00mm) 0.198" (5.03mm) 0.208" (5.28mm) 0.209" (5.31mm) 0.210" (5.33mm) 0.212" (5.39mm) 0.213" (5.41mm) 0.214" (5.44mm) 0.217" (5.51mm) 0.219" (5.56mm) 0.221" (5.61mm) 0.224" (5.69mm) 0.228" (5.79mm) 0.230" (5.84mm) 0.235" (5.97mm) 0.236" (5.99mm) 0.237" (6.02mm) 0.238" (6.04mm) 0.240" (6.10mm) 0.241" (6.12mm) 0.244" (6.20mm) 0.245" (6.22mm) 0.249" (6.32mm) 0.250" (6.35mm) 0.253" (6.43mm) 0.256" (6.50mm) 0.260" (6.60mm) 0.262" (6.65mm) 0.265" (6.73mm) 0.267" (6.78mm) 0.268" (6.81mm) 0.269" (6.83mm) 0.270" (6.86mm) 0.271" (6.88mm) 0.275" (6.99mm) 0.276" (7.01mm) 0.279" (7.09mm) 0.280" (7.11mm) 0.281" (7.14mm) 0.282" (7.16mm) 0.283" (7.20mm) 0.284" (7.21mm) 0.290" (7.37mm) 0.292" (7.42mm) 0.293" (7.44mm) 0.295" (7.49mm) 0.296" (7.52mm) 0.297" (7.54mm) 0.298" (7.57mm) 0.299" (7.59mm) 0.300" (7.62mm) 0.303" (7.70mm) 0.306" (7.77mm) 0.307" (7.80mm) 0.308" (7.82mm) 0.310" (7.87mm) 0.312" (7.92mm) 0.313" (7.95mm) 0.314" (7.98mm) 0.315" (8.00mm) 0.317" (8.05mm) 0.319" (8.10mm) 0.321" (8.15mm) 0.322" (8.18mm) 0.323" (8.20mm) 0.327" (8.31mm) 0.328" (8.33mm) 0.330" (8.38mm) 0.331" (8.41mm) 0.334" (8.48mm) 0.335" (8.51mm) 0.339" (8.61mm) 0.340" ~ 0.360" (8.64mm ~ 9.15mm) 0.342" (8.69mm) 0.343" (8.71mm) 0.344" (8.74mm) 0.346" (8.79mm) 0.346" ~ 0.354" (8.79mm ~ 8.99mm) 0.348" (8.84mm) 0.350" (8.89mm) 0.351" (8.91mm) 0.354" (9.00mm) 0.354" ~ 0.362" (9.00mm ~ 9.20mm) 0.356" (9.04mm) 0.358" (9.09mm) 0.359" (9.12mm) 0.360" (9.14mm) 0.363" (9.22mm) 0.364" (9.25mm) 0.369" (9.37mm) 0.370" (9.40mm) 0.372" (9.45mm) 0.373" (9.47mm) 0.375" (9.53mm) 0.378" (9.60mm) 0.379" (9.63mm) 0.381" (9.68mm) 0.382" (9.70mm) 0.386" (9.80mm) 0.387" (9.83mm) 0.390" (9.91mm) 0.391" (9.93mm) 0.395" (10.03mm) 0.399" (10.13mm) 0.401" (10.19mm) 0.402" (10.20mm) 0.402" ~ 0.422" (10.21mm ~ 10.71mm) 0.403" (10.24mm) 0.405" (10.29mm) 0.406" (10.30mm) 0.410" (10.41mm) 0.412" (10.46mm) 0.413" (10.49mm) 0.415" (10.54mm) 0.416" (10.57mm) 0.417" (10.59mm) 0.418" (10.62mm) 0.421" (10.69mm) 0.426" (10.82mm) 0.428" (10.87mm) 0.432" (10.97mm) 0.433" (11.00mm) 0.433" ~ 0.441" (11.00mm ~ 11.20mm) 0.435" (11.05mm) 0.437" (11.10mm) 0.438" (11.13mm) 0.441" (11.20mm) 0.442" (11.23mm) 0.443" ~ 0.463" (11.25mm ~ 11.75mm) 0.445" (11.30mm) 0.446" (11.33mm) 0.447" (11.35mm) 0.452" (11.48mm) 0.453" (11.51mm) 0.455" (11.56mm) 0.457" (11.61mm) 0.462" (11.73mm) 0.463" (11.76mm) 0.465" (11.81mm) 0.468" (11.89mm) 0.469" (11.90mm) 0.472" (12.00mm) 0.473" (12.01mm) 0.475" (12.07mm) 0.476" (12.09mm) 0.477" (12.12mm) 0.478" (12.14mm) 0.483" (12.27mm) 0.484" (12.29mm) 0.485" (12.32mm) 0.488" (12.40mm) 0.493" (12.52mm) 0.495" (12.57mm) 0.499" (12.67mm) 0.500" (12.70mm) 0.501" (12.73mm) 0.505" (12.83mm) 0.507" (12.88mm) 0.512" (13.00mm) 0.515" (13.08mm) 0.516" (13.11mm) 0.519" (13.18mm) 0.520" (13.21mm) 0.531" (13.50mm) 0.532" (13.51mm) 0.535" (13.59mm) 0.539" (13.69mm) 0.540" (13.72mm) 0.541" (13.74mm) 0.544" (13.82mm) 0.547" (13.89mm) 0.550" (13.97mm) 0.557" ~ 0.565" (14.15mm ~ 14.35mm) 0.560" (14.22mm) 0.562" (14.27mm) 0.563" (14.30mm) 0.565" (14.35mm) 0.570" (14.48mm) 0.579" (14.71mm) 0.581" (14.77mm) 0.587" ~ 0.606" (14.91mm ~ 15.39mm) 0.593" (15.06mm) 0.594" (15.09mm) 0.595" (15.11mm) 0.601" (15.27mm) 0.602" (15.29mm) 0.603" (15.32mm) 0.625" (15.88mm) 0.634" (16.10mm) 0.641" (16.28mm) 0.647" (16.43mm) 0.656" (16.66mm) 0.660" (16.76mm) 0.670" (17.02mm) 0.690" (17.53mm) 0.693" (17.60mm) 0.719" (18.26mm) 0.744" ~ 0.764" (18.90mm ~ 19.41mm) 0.760" (19.30mm) 0.777" (19.74mm) 0.785" (19.94mm) 0.793" (20.14mm) 0.800" (20.32mm) 0.807" (20.50mm) 0.810" (20.57mm) 0.821" (20.85mm) 0.830" (21.08mm) 0.836" (21.23mm) 0.837" (21.26mm) 0.878" (22.30mm) 0.885" (22.48mm) 0.902" (22.91mm) 0.938" (23.83mm) 0.988" ~ 1.015" (25.10mm ~ 25.78mm) 0.990" (25.15mm) 1.088" (27.64mm)	- Panel Mount Through Hole	- Press-Fit Press-Fit, Barbed Press-Fit, Barbed, Wire Wrap Press-Fit, Knurled Press-Fit, Knurled, Swage Press-Fit, Knurled, Wire Wrap Press-Fit, Wire Wrap Staking Flare Staking Flare, Knurled Swage Swage, Knurled Swage, Wire Wrap Threaded	- 0.047" (1.19mm) 0.059" (1.50mm) 0.062" (1.57mm) 0.063" (1.60mm) 0.064" (1.63mm) 0.070" (1.77mm) 0.070" (1.78mm) 0.071" (1.80mm) 0.072" (1.83mm) 0.078" (1.98mm) 0.079" (2.00mm) 0.090" (2.29mm) 0.091" (2.30mm) 0.093" (2.36mm) 0.094" (2.39mm) 0.098" (2.49mm) 0.111" (2.82mm) 0.115" (2.92mm) 0.118" (3.00mm) 0.125" (3.18mm) 0.125" (3.18mm) Hex 0.150" (3.81mm) 0.153" ~ 0.159" (3.88mm ~ 4.04mm) 0.156" (3.96mm) 0.156" (3.96mm) Hex 0.156" ~ 0.161" (3.96mm ~ 4.09mm) 0.171" (4.34mm) 0.172" (4.37mm) 0.173" (4.40mm) 0.184" ~ 0.190" (4.67mm ~ 4.83mm) 0.187" (4.75mm) 0.187" (4.75mm) Hex 0.188" (4.78mm) 0.188" (4.78mm) Hex 0.197" (5.00mm) 0.199" (5.06mm) 0.200" (5.08mm) 0.219" (5.56mm) 0.250" (6.35mm) 0.250" (6.35mm) Hex 0.312" (7.92mm) 0.312" (7.92mm) Hex	- 0.032" (0.81mm) 0.033" (0.84mm) 0.040" (1.02mm) 0.041" (1.04mm) 0.045" (1.14mm) 0.050" (1.27mm) 0.051" (1.30mm) 0.053" (1.35mm) 0.054" (1.37mm) 0.058" (1.47mm) 0.059" (1.50mm) 0.059" ~ 0.063" (1.50mm ~ 1.60mm) 0.060" (1.52mm) 0.061" (1.55mm) 0.062" (1.57mm) 0.062" (1.57mm), 0.093" (2.36mm) 0.063" (1.60mm) 0.064" (1.63mm) 0.067" (1.70mm), 0.089" (2.26mm) 0.070" (1.78mm) 0.070" (1.78mm), 0.109" (2.77mm) 0.071" (1.80mm) 0.072" (1.83mm) 0.073" (1.85mm) 0.075" (1.91mm) 0.078" (1.98mm) 0.079" (2.00mm) 0.080" (2.03mm) 0.082" (2.08mm) 0.082" (2.08mm), 0.145" (3.68mm) 0.086" (2.18mm) 0.089" (2.26mm), 0.097" (2.46mm) 0.089" ~ 0.094" (2.26mm ~ 2.39mm) 0.090" (2.29mm) 0.093" (2.36mm) 0.093" (2.36mm), 0.094" (2.39mm) 0.094" (2.39mm) 0.097" (2.46mm) 0.100" (2.54mm) 0.107" (2.73mm) 0.109" (2.77mm) 0.118" (3.00mm) 0.120" (3.05mm) 0.120" ~ 0.125" (3.05mm ~ 3.18mm) 0.125" (3.18mm) 0.128" (3.25mm) 0.135" ~ 0.145" (3.43mm ~ 3.68mm) 0.136" ~ 0.140" (3.45mm ~ 3.56mm) 0.137" ~ 0.140" (3.48mm ~ 3.56mm) 0.140" (3.56mm) 0.141" (3.58mm) 0.144" (3.66mm), 0.145" (3.68mm) 0.145" (3.68mm) 0.146" (3.71mm) 0.150" (3.81mm) 0.151" ~ 0.156" (3.83mm ~ 3.96mm) 0.152" (3.86mm) 0.180" (4.57mm)	- 0.030" (0.76mm) 0.031" (0.80mm) 0.039" (0.99mm) 0.040" (1.02mm) 0.046" (1.17mm) 0.047" (1.19mm) 0.048" (1.22mm) 0.049" (1.24mm) 0.055" (1.40mm) 0.057" ~ 0.060" (1.45mm ~ 1.52mm) 0.057" ~ 0.063" (1.45mm ~ 1.59mm) 0.059" (1.50mm) 0.059" ~ 0.060" (1.50mm ~ 1.52mm) 0.059" ~ 0.063" (1.50mm ~ 1.59mm) 0.060" (1.52mm) 0.061" (1.55mm) 0.061" ~ 0.064" (1.55mm ~ 1.63mm) 0.062" (1.57mm) 0.064" (1.63mm) 0.070" (1.78mm) 0.070" ~ 0.072" (1.78mm ~ 1.83mm) 0.071" (1.80mm) 0.072" (1.83mm) 0.073" (1.85mm) 0.074" ~ 0.079" (1.87mm ~ 2.01mm) 0.076" ~ 0.079" (1.93mm ~ 2.01mm) 0.078" (1.98mm) 0.079" (2.00mm) 0.080" ~ 0.083" (2.03mm ~ 2.12mm) 0.080" ~ 0.085" (2.03mm ~ 2.16mm) 0.087" (2.21mm) 0.090" (2.29mm) 0.091" (2.31mm) 0.091" ~ 0.094" (2.31mm ~ 2.39mm) 0.092" ~ 0.095" (2.34mm ~ 2.41mm) 0.100" ~ 0.105" (2.54mm ~ 2.67mm) 0.102" ~ 0.105" (2.59mm ~ 2.67mm) 0.107" ~ 0.117" (2.73mm ~ 2.98mm) 0.109" (2.77mm) 0.110" (2.79mm) 0.110" ~ 0.114" (2.79mm ~ 2.89mm) 0.112" (2.84mm) 0.122" (3.10mm) 0.122" ~ 0.125" (3.10mm ~ 3.18mm) 0.150" (3.81mm) 0.150" ~ 0.152" (3.81mm ~ 3.86mm) 0.152" ~ 0.154" (3.86mm ~ 3.92mm)	- 0.020" (0.51mm) 0.024" (0.61mm) 0.026" (0.66mm) 0.028" (0.71mm) 0.029" (0.74mm) 0.031" (0.80mm) 0.035" (0.90mm) 0.039" (1.00mm) 0.040" ~ 0.043" (1.02mm ~ 1.09mm) 0.041" (1.04mm) 0.042" (1.07mm) 0.042" ~ 0.043" (1.07mm ~ 1.09mm) 0.043" (1.09mm) 0.044" (1.12mm) 0.046" (1.17mm) 0.046" ~ 0.048" (1.17mm ~ 1.22mm) 0.046" ~ 0.049" (1.17mm ~ 1.24mm) 0.052" ~ 0.055" (1.32mm ~ 1.40mm) 0.055" (1.40mm) 0.055" ~ 0.060" (1.40mm ~ 1.53mm) 0.059" (1.50mm) 0.064" (1.63mm) 0.065" ~ 0.075" (1.65mm ~ 1.91mm) 0.067" (1.70mm) 0.067" ~ 0.070" (1.70mm ~ 1.78mm) 0.073" ~ 0.076" (1.85mm ~ 1.93mm) 0.075" (1.91mm) 0.076" (1.93mm) 0.078" (1.98mm) 0.083" (2.11mm) 0.086" ~ 0.089" (2.18mm ~ 2.26mm) 0.089" (2.26mm) 0.109" ~ 0.112" (2.77mm ~ 2.85mm)	- 0.033" (0.84mm) 0.043" (1.09mm) 0.047" (1.20mm) 0.049" ~ 0.052" (1.24mm ~ 1.32mm) 0.050" ~ 0.054" (1.27mm ~ 1.37mm) 0.052" (1.32mm) 0.053" (1.35mm) 0.056" (1.42mm) 0.057" (1.45mm) 0.060" ~ 0.063" (1.52mm ~ 1.60mm) 0.062" (1.57mm) 0.063" ~ 0.066" (1.60mm ~ 1.68mm) 0.064" (1.63mm) 0.064" ~ 0.068" (1.63mm ~ 1.72mm) 0.066" ~ 0.068" (1.68mm ~ 1.72mm) 0.067" (1.70mm) 0.069" (1.75mm) 0.072" ~ 0.074" (1.83mm ~ 1.87mm) 0.073" (1.85mm) 0.076" (1.93mm) 0.079" ~ 0.082" (2.01mm ~ 2.08mm) 0.079" ~ 0.083" (2.01mm ~ 2.11mm) 0.080" ~ 0.083" (2.03mm ~ 2.11mm) 0.082" (2.08mm) 0.084" ~ 0.087" (2.13mm ~ 2.21mm) 0.085" ~ 0.089" (2.17mm ~ 2.26mm) 0.086" (2.18mm) 0.092" (2.34mm) 0.092" ~ 0.096" (2.34mm ~ 2.44mm) 0.094" (2.39mm) 0.094" ~ 0.097" (2.39mm ~ 2.46mm) 0.095" ~ 0.099" (2.42mm ~ 2.52mm) 0.105" ~ 0.109" (2.67mm ~ 2.77mm) 0.107" ~ 0.109" (2.73mm ~ 2.77mm) 0.112" ~ 0.115" (2.85mm ~ 2.93mm) 0.113" (2.87mm) 0.114" ~ 0.117" (2.90mm ~ 2.98mm) 0.115" ~ 0.119" (2.93mm ~ 3.01mm) 0.116" (2.95mm) 0.118" (3.00mm) 0.120" (3.05mm) 0.125" (3.18mm) 0.126" ~ 0.129" (3.19mm ~ 3.28mm) 0.129" (3.28mm) 0.136" (3.45mm) 0.147" ~ 0.149" (3.74mm ~ 3.79mm) 0.152" (3.86mm) 0.154" (3.91mm) 0.155" ~ 0.159" (3.94mm ~ 4.04mm) 0.156" (3.96mm) 0.158" (4.01mm)	- 0.013" (0.32mm) 0.016" (0.41mm) 0.020" (0.50mm) 0.028" ~ 0.063" (0.72mm ~ 1.60mm) 0.031" (0.79mm) 0.032" (0.81mm) 0.047" (1.19mm) 0.062" (1.57mm) 0.062" ~ 0.094" (1.57mm ~ 2.39mm) 0.063" (1.60mm) 0.078" (1.98mm) 0.084" (2.13mm) 0.093" (2.36mm) 0.094" (2.39mm) 0.113" (2.87mm) 0.125" (3.18mm) 0.126" (3.20mm) 0.145" (3.68mm) 0.156" (3.96mm) 0.188" (4.78mm)	- Brass Brass Alloy Copper Alloy Steel, Carbon	- Gold Silver Tin Tin-Lead	- 10.0µin (0.25µm) 137.8µin (3.50µm) 20.0µin (0.51µm) 200.0µin (5.08µm) 300.0µin (7.62µm) 50.0µin (1.27µm)	- Insulated Non-Insulated

全部重置

应用所有

结果:

Mfr. Part #	Availability	Price	Quantity	Datasheet	Series	Packaging	Product Status	Terminal Type	Number of Turrets	Length - Above Board	Length - Below Flange	Length - Overall	Mounting Type	Termination	Flange Diameter	Diameter - Turret Head	Staking Side OD	Staking Side ID	Mounting Hole Diameter	Board Thickness	Contact Material	Contact Finish	Contact Finish Thickness	Insulation
1095-0-05-15-00-00-01-0 TERM TURRET PIN L=3.56MM GOLD Mill-Max Manufacturing Corp.	4,977	1.09	RFQ	Datasheet	1095	Bulk	Active	Double End, Pin	Single	0.140" (3.56mm)	0.949" (24.10mm)	1.088" (27.64mm)	Through Hole	Swage, Wire Wrap	0.115" (2.92mm)	0.053" (1.35mm)	-	-	0.094" (2.39mm)	0.062" (1.57mm)	Brass Alloy	Gold	10.0µin (0.25µm)	Non-Insulated
2812-3-00-44-00-00-07-0 TERM TURRET DOUBLE L=9.14MM Mill-Max Manufacturing Corp.	4,552	1.21	RFQ	Datasheet	2812	Bulk	Active	Double End	Double	0.360" (9.14mm)	0.477" (12.12mm)	0.837" (21.26mm)	Through Hole	Swage	0.187" (4.75mm)	0.082" (2.08mm), 0.145" (3.68mm)	-	-	0.116" (2.95mm)	0.125" (3.18mm)	Brass Alloy	Silver	300.0µin (7.62µm)	Non-Insulated
11308 TERM TURRET SINGLE L=11.1MM TIN Keystone Electronics	2,830	1.24	RFQ	Datasheet	-	Bulk	Active	Single End	Double	0.437" (11.10mm)	0.165" (4.19mm)	0.602" (15.29mm)	Through Hole	Press-Fit	0.172" (4.37mm)	0.093" (2.36mm)	-	-	0.136" (3.45mm)	0.062" (1.57mm)	Brass	Tin	-	Insulated
11320 TERM TURRET SINGLE L=3.81MM TIN Keystone Electronics	3,495	1.24	RFQ	Datasheet	-	Bulk	Active	Single End	Single	0.150" (3.81mm)	0.100" (2.54mm)	0.160" (4.06mm)	Through Hole	Press-Fit	0.172" (4.37mm)	0.080" (2.03mm)	-	-	0.136" (3.45mm)	0.062" (1.57mm)	Brass	Tin	-	Insulated
11307 TERM TURRET SINGLE L=7.37MM TIN Keystone Electronics	3,985	1.25	RFQ	Datasheet	-	Bulk	Active	Single End	Double	0.290" (7.37mm)	0.250" (6.35mm)	0.540" (13.72mm)	Through Hole	Press-Fit	0.172" (4.37mm)	0.093" (2.36mm)	-	-	0.136" (3.45mm)	0.062" (1.57mm)	Brass	Tin	-	Insulated
1095-0-05-21-00-00-01-0 TERM TURRET PIN L=3.56MM GOLD Mill-Max Manufacturing Corp.	4,440	1.37	RFQ	Datasheet	1095	Bulk	Active	Double End, Pin	Single	0.140" (3.56mm)	0.949" (24.10mm)	1.088" (27.64mm)	Through Hole	Swage, Wire Wrap	0.115" (2.92mm)	0.053" (1.35mm)	-	-	0.094" (2.39mm)	0.062" (1.57mm)	Brass Alloy	Gold	20.0µin (0.51µm)	Non-Insulated
11111 TERM TURRET HOLLOW L=9.91MM TIN Keystone Electronics	1,244	1.32	RFQ	Datasheet	-	Bulk	Active	Single End, Fork, Hollow	Single	0.390" (9.91mm)	0.150" (3.81mm)	0.540" (13.72mm)	Through Hole	Press-Fit	0.187" (4.75mm)	-	-	-	0.158" (4.01mm)	0.062" (1.57mm)	Brass	Tin	-	Insulated
11112 TERM TURRET HOLLOW L=11.51MM TIN Keystone Electronics	3,903	1.55	RFQ	Datasheet	-	Bulk	Active	Single End, Fork, Hollow	Single	0.453" (11.51mm)	0.150" (3.81mm)	0.603" (15.32mm)	Through Hole	Press-Fit	0.187" (4.75mm)	-	-	-	0.158" (4.01mm)	0.062" (1.57mm)	Brass	Tin	-	Insulated
11503 TERM TURRET SINGLE L=9.53MM TIN Keystone Electronics	2,783	264.00	RFQ	-	-	Bulk	Obsolete	Single End	Single	0.375" (9.53mm)	0.218" (5.54mm)	0.593" (15.06mm)	Panel Mount	Threaded	0.156" (3.96mm) Hex	0.093" (2.36mm)	-	-	-	-	Brass	Tin	-	Insulated
11510 TERM TURRET SINGLE L=9.93MM TIN Keystone Electronics	1,204	0.00	RFQ	Datasheet	-	Bulk	Active	Single End	Single	0.391" (9.93mm)	-	0.391" (9.93mm)	Panel Mount	Threaded	0.156" (3.96mm) Hex	0.072" (1.83mm)	-	-	-	-	Brass	Tin	-	Insulated
11500 TERM TURRET SINGLE L=9.93MM TIN Keystone Electronics	4,675	237.60	RFQ	Datasheet	-	Bulk	Active	Single End	Single	0.391" (9.93mm)	0.125" (3.18mm)	0.516" (13.11mm)	Panel Mount	Threaded	0.156" (3.96mm) Hex	0.072" (1.83mm)	-	-	-	-	Brass	Tin	-	Insulated
11501 TERM TURRET SINGLE L=11.53MM TIN Keystone Electronics	2,761	264.00	RFQ	Datasheet	-	Bulk	Active	Single End	Single	0.454" (11.53mm)	0.125" (3.18mm)	0.579" (14.71mm)	Panel Mount	Threaded	0.156" (3.96mm) Hex	0.072" (1.83mm)	-	-	-	-	Brass	Tin	-	Insulated
11502 TERM TURRET SINGLE L=11.53MM TIN Keystone Electronics	2,781	264.00	RFQ	Datasheet	-	Bulk	Active	Single End	Single	0.454" (11.53mm)	0.187" (4.75mm)	0.641" (16.28mm)	Panel Mount	Threaded	0.156" (3.96mm) Hex	0.072" (1.83mm)	-	-	-	-	Brass	Tin	-	Insulated
11511 TERM TURRET SINGLE L=13.89MM TIN Keystone Electronics	4,623	0.00	RFQ	Datasheet	-	Bulk	Active	Single End	Single	0.547" (13.89mm)	-	0.547" (13.89mm)	Panel Mount	Threaded	0.156" (3.96mm) Hex	0.072" (1.83mm)	-	-	-	-	Brass	Tin	-	Insulated
11512 TERM TURRET SINGLE L=15.09MM TIN Keystone Electronics	1,772	0.00	RFQ	Datasheet	-	Bulk	Active	Single End	Double	0.594" (15.09mm)	-	0.594" (15.09mm)	Panel Mount	Threaded	0.250" (6.35mm) Hex	0.093" (2.36mm)	-	-	-	-	Brass	Tin	-	Insulated
11513 TERM TURRET SINGLE L=23.83MM TIN Keystone Electronics	1,992	6.36	RFQ	Datasheet	-	Bulk	Active	Single End	Double	0.938" (23.83mm)	-	0.938" (23.83mm)	Panel Mount	Threaded	0.250" (6.35mm) Hex	0.140" (3.56mm)	-	-	-	-	Brass	Tin	-	Insulated
2512-1-00-44-00-00-07-0 TERM TURRET DOUBLE L=5.56MM Mill-Max Manufacturing Corp.	3,646	0.00	RFQ	Datasheet	2512	Bulk	Active	Double End	Double	0.219" (5.56mm)	0.250" (6.35mm)	0.469" (11.90mm)	Through Hole	Swage	0.125" (3.18mm)	0.064" (1.63mm)	-	-	0.094" (2.39mm)	0.031" (0.79mm)	Brass Alloy	Silver	300.0µin (7.62µm)	Non-Insulated
2513-3-00-50-00-00-07-0 TERM TURRET SINGLE L=4.78MM Mill-Max Manufacturing Corp.	3,252	0.00	RFQ	Datasheet	2513	Bulk	Active	Single End	Double	0.188" (4.78mm)	0.125" (3.18mm)	0.313" (7.95mm)	Through Hole	Swage	0.125" (3.18mm)	0.060" (1.52mm)	0.060" (1.52mm)	0.041" (1.04mm)	0.064" (1.63mm)	0.094" (2.39mm)	Brass Alloy	Tin-Lead	300.0µin (7.62µm)	Non-Insulated
2561-1-00-01-00-00-07-0 TERM TURRET SINGLE L=5.56MM Mill-Max Manufacturing Corp.	4,324	0.00	RFQ	Datasheet	2561	Bulk	Active	Single End	Double	0.219" (5.56mm)	0.063" (1.60mm)	0.282" (7.16mm)	Through Hole	Swage	0.125" (3.18mm)	0.094" (2.39mm)	0.090" (2.29mm)	0.064" (1.63mm)	0.094" (2.39mm)	0.031" (0.79mm)	Brass Alloy	Tin-Lead	200.0µin (5.08µm)	Non-Insulated
2561-4-00-50-00-00-07-0 TERM TURRET SINGLE L=5.56MM Mill-Max Manufacturing Corp.	2,866	0.00	RFQ	Datasheet	2561	Bulk	Active	Single End	Double	0.219" (5.56mm)	0.156" (3.96mm)	0.375" (9.53mm)	Through Hole	Swage	0.125" (3.18mm)	0.094" (2.39mm)	0.090" (2.29mm)	0.064" (1.63mm)	0.094" (2.39mm)	0.125" (3.18mm)	Brass Alloy	Tin-Lead	300.0µin (7.62µm)	Non-Insulated
