Signal Relays, Up to 2 Amps
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | Mounting Type | Coil Voltage | Contact Form | Contact Rating (Current) | Switching Voltage | Load - Max Switching | Coil Current | Coil Type | Features | Termination Style | Seal Rating | Coil Insulation | Must Operate Voltage | Must Release Voltage | Operate Time | Release Time | Operating Temperature | Contact Material | Relay Type | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
AGQ20TS2HXRELAY GEN PURPOSE DPDT 2A 2.4V |
592 | 3.79 |
|
Datasheet |
AGQ TH | Tape & Reel (TR) | Active | Surface Mount | 2.4VDC | DPDT (2 Form C) | 2 A | 125VAC, 110VDC - Max | 250VA, 220W | 58.5 mA | Non Latching | - | Gull Wing | - | - | 1.8 VDC | 0.24 VDC | 4 ms | 4 ms | -40°C ~ 85°C | Silver Nickel (AgNi), Gold (Au) | General Purpose | - | - |
|
TX2SA-L2-24VRELAY TELECOM DPDT 2A 24V |
490 | 5.13 |
|
Datasheet |
TX | Tube | Active | Surface Mount | 24VDC | DPDT (2 Form C) | 2 A | 220VDC - Max | 440VA | 8.3 mA | Latching, Dual Coil | - | Gull Wing | Sealed - Fully | - | 18 VDC | - | 4 ms | 4 ms | -40°C ~ 85°C | Silver (Ag), Gold (Au) | Telecom | - | - |
|
J850SM2CS12VDCRELAY GEN PURPOSE DPDT 1A 12V |
945 | 2.05 |
|
Datasheet |
J850SM | Tape & Reel (TR) | Active | Surface Mount | 12VDC | DPDT (2 Form C) | 1 A | 250VAC, 220VDC - Max | 250VA, 220W | 11.7 mA | Non Latching | - | Gull Wing | Sealed - Fully | - | 9 VDC | 1.2 VDC | 2 ms | 1 ms | -40°C ~ 85°C | Silver Palladium (AgPd), Gold (Au) | General Purpose | - | - |
|
AGQ20T09RELAY GENERAL PURPOSE DPDT 2A 9V |
226 | 3.55 |
|
Datasheet |
AGQ TH | Tube | Active | Through Hole | 9VDC | DPDT (2 Form C) | 2 A | 125VAC, 110VDC - Max | 250VA, 220W | 15.5 mA | Non Latching | - | PC Pin | - | - | 6.75 VDC | 0.9 VDC | 4 ms | 4 ms | -40°C ~ 85°C | Silver Nickel (AgNi), Gold (Au) | General Purpose | - | - |
|
|
AGQ21T1HRELAY GEN PURPOSE DPDT 2A 1.5V |
150 | 3.68 |
|
Datasheet |
AGQ TH | Tube | Active | Through Hole | 1.5VDC | DPDT (2 Form C) | 2 A | 125VAC, 110VDC - Max | 250VA, 220W | 66.7 mA | Latching, Single Coil | - | PC Pin | - | - | 1.13 VDC | - | 4 ms | 4 ms | -40°C ~ 85°C | Silver Nickel (AgNi), Gold (Au) | General Purpose | - | - |
|
EE2-12TNUH-LRELAY GEN PURPOSE DPDT 2A 12V |
5,999 | 3.29 |
|
Datasheet |
EE2 | Tape & Reel (TR) | Active | Surface Mount | 12VDC | DPDT (2 Form C) | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 11.7 mA | Latching, Dual Coil | - | Gull Wing | - | - | 9 VDC | - | 2 ms | 1 ms | -40°C ~ 85°C | Silver Alloy, Gold Alloy | General Purpose | - | - |
.JPG)
|
EE2-4.5TNU-LRELAY GEN PURPOSE DPDT 2A 4.5V |
578 | 3.44 |
|
Datasheet |
EE2 | Tape & Reel (TR) | Active | Surface Mount | 4.5VDC | DPDT (2 Form C) | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 31.1 mA | Latching, Dual Coil | - | Gull Wing | - | - | 3.38 VDC | - | 2 ms | 1 ms | -40°C ~ 85°C | Silver Alloy, Gold Alloy | General Purpose | - | - |
|
TXD2SA-5VRELAY GENERAL PURPOSE DPDT 2A 5V |
737 | 3.52 |
|
Datasheet |
TX-D | Tube | Active | Surface Mount | 5VDC | DPDT (2 Form C) | 2 A | 220VDC - Max | 440W | 40 mA | Non Latching | - | Gull Wing | Sealed - Fully | - | 3.75 VDC | 0.5 VDC | 4 ms | 4 ms | -40°C ~ 85°C | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
TX2SA-9VRELAY TELECOM DPDT 2A 9V |
1,110 | 3.55 |
|
Datasheet |
TX | Tube | Active | Surface Mount | 9VDC | DPDT (2 Form C) | 2 A | 220VDC - Max | 440VA | 15.5 mA | Non Latching | - | Gull Wing | Sealed - Fully | - | 6.75 VDC | 0.9 VDC | 4 ms | 4 ms | -40°C ~ 85°C | Silver (Ag), Gold (Au) | Telecom | - | - |
|
TQ2SA-L2-4.5VRELAY TELECOM DPDT 2A 4.5V |
11,313 | 4.54 |
|
Datasheet |
TQ-SMD | Tube | Active | Surface Mount | 4.5VDC | DPDT (2 Form C) | 2 A | 125VAC, 220VDC - Max | 250VA, 440W | 31 mA | Latching, Dual Coil | - | Gull Wing | - | - | 3.38 VDC | - | 4 ms | 4 ms | -40°C ~ 85°C | Silver Nickel (AgNi), Gold (Au) | Telecom | - | - |
|
TQ2SA-9V-ZRELAY TELECOM DPDT 2A 9V |
1,430 | 3.60 |
|
Datasheet |
TQ-SMD | Tape & Reel (TR) | Active | Surface Mount | 9VDC | DPDT (2 Form C) | 2 A | 125VAC, 220VDC - Max | 250VA, 440W | 15.5 mA | Non Latching | - | Gull Wing | - | - | 6.75 VDC | 0.9 VDC | 4 ms | 4 ms | -40°C ~ 85°C | Silver Nickel (AgNi), Gold (Au) | Telecom | - | - |
|
TX2-LT-3V-THRELAY GENERAL PURPOSE DPDT 2A 3V |
971 | 5.21 |
|
Datasheet |
TX-TH | Tube | Active | Through Hole | 3VDC | DPDT (2 Form C) | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 46.7 mA | Latching, Dual Coil | - | PC Pin | Sealed - Fully | - | 2.25 VDC | - | 4 ms | 4 ms | -40°C ~ 85°C | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
G6SU-2 DC12RELAY TELECOM DPDT 2A 12V |
785 | 4.73 |
|
Datasheet |
G6S | Tube | Active | Through Hole | 12VDC | DPDT (2 Form C) | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 8.3 mA | Latching, Single Coil | - | PC Pin | - | - | 9 VDC | - | 4 ms | 4 ms | -40°C ~ 85°C | Silver (Ag), Gold (Au) | Telecom | - | - |
|
|
AGQ21TS4HXRELAY GEN PURPOSE DPDT 2A 4.5V |
2,150 | 3.79 |
|
Datasheet |
AGQ TH | Tape & Reel (TR) | Active | Surface Mount | 4.5VDC | DPDT (2 Form C) | 2 A | 125VAC, 110VDC - Max | 250VA, 220W | 22.2 mA | Latching, Single Coil | - | Gull Wing | - | - | 3.38 VDC | - | 4 ms | 4 ms | -40°C ~ 85°C | Silver Nickel (AgNi), Gold (Au) | General Purpose | - | - |
|
G6L-1F-TR DC4.5RELAY TELECOM SPST 1A 4.5V |
3,795 | 0.00 |
|
Datasheet |
G6L | Tape & Reel (TR) | Active | Surface Mount | 4.5VDC | SPST-NO (1 Form A) | 1 A | 125VAC, 60VDC - Max | 125VA, 60W | 40 mA | Non Latching | - | Gull Wing | Sealed - Fully | - | 3.38 VDC | 0.45 VDC | 5 ms | 5 ms | -40°C ~ 70°C | - | Telecom | - | - |
|
|
TX2SA-6VRELAY TELECOM DPDT 2A 6V |
1,078 | 3.63 |
|
Datasheet |
TX | Tube | Active | Surface Mount | 6VDC | DPDT (2 Form C) | 2 A | 220VDC - Max | 440VA | 23.3 mA | Non Latching | - | Gull Wing | Sealed - Fully | - | 4.5 VDC | 0.6 VDC | 4 ms | 4 ms | -40°C ~ 85°C | Silver (Ag), Gold (Au) | Telecom | - | - |
|
G6SU-2F DC3RELAY TELECOM DPDT 2A 3V |
6,450 | 4.45 |
|
Datasheet |
G6S | Tube | Active | Surface Mount | 3VDC | DPDT (2 Form C) | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 33.3 mA | Latching, Single Coil | - | Gull Wing | - | - | 2.25 VDC | - | 4 ms | 4 ms | -40°C ~ 85°C | Silver (Ag), Gold (Au) | Telecom | - | - |
|
TQ2-2M-24VRELAY TELECOM DPDT 1A 24V |
1,311 | 4.65 |
|
Datasheet |
TQ | Tube | Active | Through Hole | 24VDC | DPDT (2 Form D) | 1 A | 125VAC, 110VDC - Max | 125VA, 110W | 8.3 mA | Non Latching | - | PC Pin | - | - | 19.2 VDC | 2.4 VDC | 3 ms | 3 ms | -40°C ~ 50°C | Silver (Ag), Gold (Au) | Telecom | - | - |
|
EE2-3SNU-LRELAY GENERAL PURPOSE DPDT 2A 3V |
4,140 | 3.44 |
|
Datasheet |
EE2 | Tape & Reel (TR) | Active | Surface Mount | 3VDC | DPDT (2 Form C) | 2 A | 250VAC, 220VDC - Max | 500VA, 440W | 33.3 mA | Latching, Single Coil | - | Gull Wing | - | - | 2.25 VDC | - | 2 ms | 1 ms | -40°C ~ 85°C | Silver Alloy, Gold Alloy | General Purpose | - | - |
|
|
TX2SS-5V-ZRELAY TELECOM DPDT 2A 5V |
2,005 | 3.68 |
|
Datasheet |
TX | Tape & Reel (TR) | Active | Surface Mount | 5VDC | DPDT (2 Form C) | 2 A | 220VDC - Max | 440VA | 28.1 mA | Non Latching | - | Gull Wing | Sealed - Fully | - | 3.75 VDC | 0.5 VDC | 4 ms | 4 ms | -40°C ~ 85°C | Silver (Ag), Gold (Au) | Telecom | - | - |
