Rotary Switches
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | Number of Positions | Index Stops | Number of Decks | Number of Poles per Deck | Circuit per Deck | Contact Timing | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Actuator Type | Actuator Length | Angle of Throw | Contact Material | Contact Finish | Mounting Type | Termination Style | Features | Depth Behind Panel |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
75BF36-01-1-07NSWITCH ROTARY 7POS 200MA 115V Grayhill Inc. |
4,889 | 27.38 |
|
Datasheet |
75 | Bulk | Active | 7 | Fixed | 1 | 1 | SP7T | Non-Shorting (BBM) | 200mA (AC/DC) | 115 V | 30 V | Flatted (3.17mm Dia) | 9.53mm | 36° | Silver Cadmium Oxide (AgCdO) | Gold | Panel Mount, Through Hole | PC Pin | - | 13.97mm |
|
|
75BF36-01-1-10N-CSWITCH ROTARY 10POS 200MA 115V Grayhill Inc. |
3,211 | 27.38 |
|
Datasheet |
75 | Bulk | Active | 10 | Continuous | 1 | 1 | SP10T | Non-Shorting (BBM) | 200mA (AC/DC) | 115 V | 30 V | Flatted (3.17mm Dia) | 9.53mm | 36° | Silver Cadmium Oxide (AgCdO) | Gold | Panel Mount, Through Hole | PC Pin | - | 13.97mm |
|
|
75BF36-01-1-10N-FSWITCH ROTARY 10POS 200MA 115V Grayhill Inc. |
4,389 | 27.38 |
|
Datasheet |
75 | Bulk | Active | 10 | Fixed | 1 | 1 | SP10T | Non-Shorting (BBM) | 200mA (AC/DC) | 115 V | 30 V | Flatted (3.17mm Dia) | 9.53mm | 36° | Silver Cadmium Oxide (AgCdO) | Gold | Panel Mount, Through Hole | PC Pin | - | 13.97mm |
|
|
50KSP45-01-2-04NSWITCH ROTARY 4POS 150MA 115V Grayhill Inc. |
3,315 | 29.98 |
|
Datasheet |
50 | Bulk | Active | 4 | Fixed | 1 | 2 | DP4T | Non-Shorting (BBM) | 150mA (AC), 200mA (DC) | 115 V | 28 V | Flatted (6.35mm Dia) | 9.53mm | 45° | - | Gold | Panel Mount, Through Hole | PC Pin | Shaft and Panel Sealed | 13.64mm |
|
|
71EF30-02-1-12N-CSWITCH ROTARY 12POS 250MA 115V Grayhill Inc. |
2,407 | 29.43 |
|
Datasheet |
71 | Bulk | Active | 12 | Continuous | 2 | 1 | SP12T | Non-Shorting (BBM) | 250mA (AC/DC) | 115 V | 30 V | Round (4mm Dia) | 17.00mm | 30° | Silver Alloy | - | Panel Mount, Through Hole, Right Angle | PC Pin | - | 24.87mm |
|
|
71EF30-02-1-09SSWITCH ROTARY 9POS 250MA 115V Grayhill Inc. |
1,092 | 29.43 |
|
- |
71 | Bulk | Active | 9 | Fixed | 2 | 1 | SP9T | Shorting (MBB) | 250mA (AC/DC) | 115 V | 30 V | Flatted (3.17mm Dia) | 9.53mm | 30° | Silver Alloy | - | Panel Mount, Through Hole, Right Angle | PC Pin | - | 27.87mm |
|
|
50KSPT36-01-2-03NSWITCH ROTARY 3POS 150MA 115V Grayhill Inc. |
1,240 | 30.04 |
|
Datasheet |
50 | Bulk | Active | 3 | Fixed | 1 | 2 | DP3T | Non-Shorting (BBM) | 150mA (AC), 200mA (DC) | 115 V | 28 V | Flatted (6.35mm Dia) | 9.53mm | 36° | - | Gold | Panel Mount, Through Hole | PC Pin | Process Sealed, Shaft and Panel Sealed | 14.63mm |
|
|
50KSPT36-01C05NSWITCH ROTARY 5POS 150MA 115V Grayhill Inc. |
1,923 | 30.04 |
|
Datasheet |
50 | Bulk | Active | 5 | Fixed | 1 | 2 | DP5T | Non-Shorting (BBM) | 150mA (AC), 200mA (DC) | 115 V | 28 V | Flatted (3.17mm Dia) | 9.53mm | 36° | - | Gold | Panel Mount, Through Hole | PC Pin | Process Sealed, Shaft and Panel Sealed | 14.63mm |
|
|
71BT36-02-2-04NSWITCH ROTARY 4POS 250MA 115V Grayhill Inc. |
4,897 | 30.05 |
|
Datasheet |
71 | Bulk | Active | 4 | Fixed | 2 | 2 | DP4T | Non-Shorting (BBM) | 250mA (AC/DC) | 115 V | 30 V | Flatted (6.35mm Dia) | 9.53mm | 36° | Silver Alloy | - | Panel Mount, Through Hole, Right Angle | PC Pin | Process Sealed | 26.42mm |
|
55P30-01-4-03NSWITCH ROTARY 3POS 200MA 115V Grayhill Inc. |
1,717 | 22.53 |
|
Datasheet |
55 | Bulk | Active | 3 | Fixed | 1 | 4 | 4P3T | Non-Shorting (BBM) | 200mA (AC/DC) | 115 V | 30 V | Flatted (3.17mm Dia) | 9.53mm | 30° | Brass | Silver | Panel Mount, Through Hole | PC Pin | - | 13.51mm |
