Digital Isolators
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Technology | Type | Isolated Power | Number of Channels | Inputs - Side 1/Side 2 | Channel Type | Voltage - Isolation | Common Mode Transient Immunity (Min) | Data Rate | Propagation Delay tpLH / tpHL (Max) | Pulse Width Distortion (Max) | Rise / Fall Time (Typ) | Voltage - Supply | Grade | Qualification | Operating Temperature | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SI86S661EE-IS26.0 KVRMS ISOLATOR, 6 UNIDIRECTI |
2,463 | 6.52 |
|
Datasheet |
- | 16-SOIC (0.295", 7.50mm Width) | Tube | Active | Capacitive Coupling | General Purpose | No | 6 | 5/1 | Unidirectional | 6000Vrms | 100kV/µs | 150Mbps | 14ns, 14ns | 2ns | 2.5ns, 2.5ns | 2.25V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 16-SOIC |
|
|
SI86SS51EE-IS23.75 KVRMS SPI COMPATIBLE ISOLAT |
2,968 | 6.52 |
|
Datasheet |
- | 16-SOIC (0.295", 7.50mm Width) | Tube | Active | Capacitive Coupling | SPI | No | 5 | 4/1 | Unidirectional | 3750Vrms | 100kV/µs | 150Mbps | 14ns, 14ns | 2ns | 2.5ns, 2.5ns | 2.25V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 16-SOIC |
|
|
SI86S663EE-IS26.0 KVRMS ISOLATOR, 6 UNIDIRECTI |
2,451 | 6.52 |
|
Datasheet |
- | 16-SOIC (0.295", 7.50mm Width) | Tube | Active | Capacitive Coupling | General Purpose | No | 6 | 3/3 | Unidirectional | 6000Vrms | 100kV/µs | 150Mbps | 14ns, 14ns | 2ns | 2.5ns, 2.5ns | 2.25V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 16-SOIC |
|
|
SI86S660EE-IS26.0 KVRMS ISOLATOR, 6 UNIDIRECTI |
2,352 | 6.52 |
|
Datasheet |
- | 16-SOIC (0.295", 7.50mm Width) | Tube | Active | Capacitive Coupling | General Purpose | No | 6 | 6/0 | Unidirectional | 6000Vrms | 100kV/µs | 150Mbps | 14ns, 14ns | 2ns | 2.5ns, 2.5ns | 2.25V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 16-SOIC |
|
|
SI86S662EE-IS26.0 KVRMS ISOLATOR, 6 UNIDIRECTI |
3,406 | 6.52 |
|
Datasheet |
- | 16-SOIC (0.295", 7.50mm Width) | Tube | Active | Capacitive Coupling | General Purpose | No | 6 | 4/2 | Unidirectional | 6000Vrms | 100kV/µs | 150Mbps | 14ns, 14ns | 2ns | 2.5ns, 2.5ns | 2.25V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 16-SOIC |
|
|
SI86SS51BE-IS23.75 KVRMS SPI COMPATIBLE ISOLAT |
4,977 | 6.52 |
|
Datasheet |
- | 16-SOIC (0.295", 7.50mm Width) | Tube | Active | Capacitive Coupling | SPI | No | 5 | 4/1 | Unidirectional | 3750Vrms | 100kV/µs | 150Mbps | 14ns, 14ns | 2ns | 2.5ns, 2.5ns | 2.25V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 16-SOIC |
|
|
SI86S662BE-IS26.0 KVRMS ISOLATOR, 6 UNIDIRECTI |
1,665 | 6.52 |
|
Datasheet |
- | 16-SOIC (0.295", 7.50mm Width) | Tube | Active | Capacitive Coupling | General Purpose | No | 6 | 4/2 | Unidirectional | 6000Vrms | 100kV/µs | 150Mbps | 14ns, 14ns | 2ns | 2.5ns, 2.5ns | 2.25V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 16-SOIC |
|
BM67220FV-CE2DGTL ISO 2500VRMS 2CH GP 20SSOP |
4,395 | 5.10 |
|
Datasheet |
- | 20-SSOP (0.240", 6.10mm Width) | Tape & Reel (TR) | Not For New Designs | Magnetic Coupling | General Purpose | No | 2 | 2/0 | Unidirectional | 2500Vrms | 35kV/µs (Typ) | - | 45ns, 45ns | - | 2.5ns, 2.5ns | 4.5V ~ 5.5V | Automotive | AEC-Q100 | -40°C ~ 125°C | Surface Mount | 20-SSOP-BW |
|
|
ADUM6211BRSZ-RL7DGTL ISO 3750VRMS 2CH GP 20SSOP |
3,981 | 8.18 |
|
Datasheet |
IsoPower®, iCoupler® | 20-SSOP (0.209", 5.30mm Width) | Tape & Reel (TR) | Active | Magnetic Coupling | General Purpose | Yes | 2 | 1/1 | Unidirectional | 3750Vrms | 25kV/µs | 25Mbps | 35ns, 35ns | 3ns | 2.5ns, 2.5ns | 2.7V ~ 5.5V | - | - | -40°C ~ 105°C | Surface Mount | 20-SSOP |
|
|
MAX22565CAAP+T6 CHANNEL REINFORCED ISOLATOR |
1,720 | 0.00 |
|
Datasheet |
- | 20-SSOP (0.209", 5.30mm Width) | Tape & Reel (TR) | Active | Capacitive Coupling | CAN, RS232, RS422, RS485, SPI | No | 6 | 5/1 | Unidirectional | 3750Vrms | 50kV/µs (Typ) | 200Mbps | 9.5ns, 9.9ns | 2ns | 800µs, 1ns | 1.71V ~ 5.5V | Automotive | AEC-Q100 | -40°C ~ 125°C | Surface Mount | 20-SSOP |
|
SI8463BA-B-IS1RDGTL ISO 1000VRMS 6CH GP 16SOIC |
3,660 | 6.53 |
|
Datasheet |
- | 16-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Not For New Designs | Capacitive Coupling | General Purpose | No | 6 | 3/3 | Unidirectional | 1000Vrms | 25kV/µs (Typ) | 150Mbps | 9.5ns, 9.5ns | 2.5ns | 3.8ns, 2.8ns | 2.7V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 16-SOIC |
|
|
MAX22165CAEE+MAX22165CAEE+ |
4,138 | 0.00 |
|
Datasheet |
- | 16-SSOP (0.154", 3.90mm Width) | Bulk | Active | Capacitive Coupling | CAN, RS232, RS422, RS485, SPI | No | 6 | 5/1 | Unidirectional | 3000Vrms | 50kV/µs (Typ) | 200Mbps | 9.5ns, 9.9ns | 2ns | 0.8ns, 1ns (Max) | 1.71V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 16-QSOP |
|
ADUM4470ARIZ-RLDGTL ISO 5000VRMS 4CH GP 20SOIC |
4,711 | 7.53 |
|
Datasheet |
IsoPower®, iCoupler® | 20-SOIC (0.295", 7.50mm Width) | Tape & Reel (TR) | Active | Magnetic Coupling | General Purpose | Yes | 4 | 4/0 | Unidirectional | 5000Vrms | 25kV/µs | 1Mbps | 100ns, 100ns | 40ns | 2.5ns, 2.5ns | 3V ~ 3.6V, 4.5V ~ 5.5V | - | - | -40°C ~ 105°C | Surface Mount | 20-SOIC-IC |
|
|
ADUM4473ARIZ-RLDGTL ISO 5000VRMS 4CH GP 20SOIC |
2,142 | 7.53 |
|
Datasheet |
IsoPower®, iCoupler® | 20-SOIC (0.295", 7.50mm Width) | Tape & Reel (TR) | Active | Magnetic Coupling | General Purpose | Yes | 4 | 1/3 | Unidirectional | 5000Vrms | 25kV/µs | 1Mbps | 100ns, 100ns | 40ns | 2.5ns, 2.5ns | 3V ~ 3.6V, 4.5V ~ 5.5V | - | - | -40°C ~ 105°C | Surface Mount | 20-SOIC-IC |
|
|
SI8600AC-ASAUTOMOTIVE 3.75 KV 2-CHANNEL BI- |
3,578 | 0.00 |
|
Datasheet |
- | 8-SOIC (0.154", 3.90mm Width) | Tube | Active | Capacitive Coupling | I2C | Yes | 2 | 2/0 | Bidirectional, Unidirectional | 3750Vrms | 35kV/µs | - | 20ns, 20ns | 12ns | 2.5ns, 2.5ns | 3V ~ 5.5V | Automotive | AEC-Q100 | -40°C ~ 125°C | Surface Mount | 8-SOIC |
|
|
SI8661BD-AS2AUTOMOTIVE 5 KV 5 FORWARD & 1 RE |
2,465 | 0.00 |
|
Datasheet |
- | 16-SOIC (0.295", 7.50mm Width) | Tube | Active | Capacitive Coupling | General Purpose | Yes | 6 | 5/1 | Unidirectional | 5000Vrms | 35kV/µs | 150Mbps | 13ns, 13ns | 4.5ns | 2.5ns, 2.5ns | 2.375V ~ 5.5V | Automotive | AEC-Q100 | -40°C ~ 125°C | Surface Mount | 16-SOIC |
|
|
SI88340ED-ASRLINEAR IC |
4,590 | 0.00 |
|
Datasheet |
Si88x4x | 24-SOIC (0.295", 7.50mm Width) | Tape & Reel (TR) | Active | Capacitive Coupling | General Purpose | Yes | 4 | 4/0 | Unidirectional | 5000Vrms | 40kV/µs | 100Mbps | 18ns, 23ns | 7ns | 2.5ns, 2.5ns | 3V ~ 5.5V | Automotive | AEC-Q100 | -40°C ~ 125°C | Surface Mount | 24-SOIC |
|
|
SI88341ED-ASRLINEAR IC |
2,555 | 0.00 |
|
Datasheet |
Si88x4x | 24-SOIC (0.295", 7.50mm Width) | Tape & Reel (TR) | Active | Capacitive Coupling | General Purpose | Yes | 4 | 3/1 | Unidirectional | 5000Vrms | 40kV/µs | 100Mbps | 18ns, 23ns | 7ns | 2.5ns, 2.5ns | 3V ~ 5.5V | Automotive | AEC-Q100 | -40°C ~ 125°C | Surface Mount | 24-SOIC |
|
|
SI88342ED-ASRLINEAR IC |
2,007 | 0.00 |
|
Datasheet |
Si88x4x | 24-SOIC (0.295", 7.50mm Width) | Tape & Reel (TR) | Active | Capacitive Coupling | General Purpose | Yes | 4 | 2/2 | Unidirectional | 5000Vrms | 40kV/µs | 100Mbps | 18ns, 23ns | 7ns | 2.5ns, 2.5ns | 3V ~ 5.5V | Automotive | AEC-Q100 | -40°C ~ 125°C | Surface Mount | 24-SOIC |
|
|
SI88344ED-ASRLINEAR IC |
1,371 | 0.00 |
|
Datasheet |
Si88x4x | 24-SOIC (0.295", 7.50mm Width) | Tape & Reel (TR) | Active | Capacitive Coupling | General Purpose | Yes | 4 | 0/4 | Unidirectional | 5000Vrms | 40kV/µs | 100Mbps | 18ns, 23ns | 7ns | 2.5ns, 2.5ns | 3V ~ 5.5V | Automotive | AEC-Q100 | -40°C ~ 125°C | Surface Mount | 24-SOIC |
